Huawei UPS2000-G Series User Manual

B Parallel Parameter List
Parallel Parameter Synchronizat
ion
Parallel Parameter Synchronizati
on
Parallel system
redundant UPSs
Yes ECO frequency range Yes
Voltage level Yes ECO max. voltage Yes
Volt. adj. coef. Yes ECO min. voltage Yes
Output transformer Yes Output mode Yes
Frequency level Yes Auto check bus capa. Yes
ECO enabled Yes Auto start Yes
Recovery delay time Yes Bypass max. voltage Yes
Bypass frequency
range
Yes Bypass min. voltage Yes
Self-load output
power ratio
Yes Generator mode Yes
Max. BPS transfers Yes EOD auto-start Yes
Converter mode Yes Self-load mode Yes
Battery capacity Yes Charge current Yes
NO TE
You can set parameters on one UPS, and then synchronize the parameters to the other
UPSs.
UPS2000-G-(6 kVA-20 kVA)
User Manual B Parallel Parameter List
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 137

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
