Huawei UPS2000-G Series User Manual

Figure 2-6 Front and rear views of the UPS2000-G-15KRTL-01/UPS2000-
G-20KRTL-01
(1) Control panel (2) AC input ports
(mains and bypass)
(3) Battery terminals (4) EPO port
(5) Maintenance
bypass port (MBS)
(6) Parallel ports (7) CAN
communications ports
(MON1 and MON2)
(8) USB port
(protected by a
security mechanism)
(9) Battery
temperature sensor
port
(10) Optional card slot (11) AC output ports
(pL and sL)
NO TE
It is recommended that the length of the cable connected to the MBS port be less than or
equal to 10 m.
2.4 Optional Components
NO TICE
For UPS2000-G-10 kVA/15 kVA/20 kVA, if the AC input and AC output use two live
wires, PDC-0038V4ACIOA, PDC-0091V2ACIOA, and PDC-0038V4ACIOA-V2 cannot
be used.
UPS2000-G-(6 kVA-20 kVA)
User Manual 2 Quick Introduction
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 25

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
