Huawei UPS2000-G Series User Manual

Item Description
Ambient humidity Humidity detected by the ambient T/H sensor
(used together with an SNMP card; if the sensor is
not connected, N/A is displayed.)
Internal temp. Temperature of the air near the air intake vent of
the UPS
Runtime
Figure 4-17 Runtime screen
Table 4-13 Runtime
Item
Description
Inv. runtime Total time during which the UPS runs in inverter
mode
BPS runtime Total time during which the UPS runs in bypass
mode
4.6.2 Alarms
On the Main Menu screen, choose Alarms and press
. The Alarms screen is
displayed.
NO TE
When the buzzer buzzes, hold down for 2–5 seconds. The buzzer is muted when you
release the button. After the buzzer is muted, the alarm sound cannot be restored until a
new alarm is generated.
Active Alarms
This screen displays the active alarm information, such as the alarm serial number,
severity, ID, and name, as shown in Figure 4-18.
Figure 4-18 Active Alarms screen
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 63

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
