Huawei UPS2000-G Series User Manual

Control Buzzer
If the buzzer is on, you can tap Control Buzzer and conrm Buzzer o to turn it
o.
Figure 4-53 Buzzer o screen
NO TE
If Control Buzzer is used to mute the alarm sound, use it to enable the alarm sound later.
Otherwise, if a new alarm is generated, there is no alarm sound. If the UPS is shut down
and powered on again, the buzzer is turned on again.
If the buzzer is o, you can tap Control Buzzer and conrm Buzzer on to turn it
on.
Figure 4-54 Buzzer on screen
4.6.5 About
On the Main Menu screen, select About, and press . The About screen is
displayed, as shown in Figure 4-55.
You can view the UPS model, equipment serial number (ESN), and version
number.
Figure 4-55 About screen
NO TE
MU1MSW1, PU1RSW1, PU1RSW2, PU1ISW1, and PU1ISW2 are the software versions for
the component. When the component does not exist, N/A is displayed. PU1ISW1 and
PU1ISW2 are not available for the 6 kVA and 10 kVA models.
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 94

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
