Table 4-1 Indicator description
Indicator Color Status Meaning
Mains indicator Green On The UPS is in normal mode.
O The UPS is not in normal mode.
Battery indicator Yellow On The UPS is in battery mode.
O The UPS is not in battery mode.
Blinking The remaining battery capacity is
less than 25%.
Bypass indicator Yellow On The UPS is in bypass mode.
O The UPS is not in bypass mode.
Fault indicator/
INFO button
Red On The UPS is faulty.
Red Blinking The UPS generates an alarm.
Green On The UPS is running properly.
The UPS is in ECO mode when the mains indicator and bypass indicator are both on.
4.3 Buttons
Five buttons are provided for you to start and shut down the UPS, and view and
set parameters. Table 4-2 describes the
ve buttons.
Table 4-2 Button description
Butt
on
Function Description
ESC Back/Shutdown ● On the default screen, press ESC for more
than 5 seconds. Release the button when
you hear a beep sound. The inverter shuts
down.
● On any other screen, press ESC to return to
the upper-level menu. (The upper-level
screen for the main menu list is the default
screen.)
▲ Up Press ▲ or ▼ to scroll upward or downward.
You can set a value by using the list or step
increase or decrease.
▼ Down
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 52
To Next Page
