Mains Input
Figure 4-6 Mains Input screen
Table 4-5 Mains Input
Item Description
Van/Vbn/Vcn Mains input phase voltage (Voltage is displayed
when single-phase output mode is set.)
Frequency Mains input frequency
Vab/Vbc/Vca Mains input line voltage (The parameters are not
displayed in the case of single-phase input.)
Bypass Input
Figure 4-7 Bypass Input screen
Table 4-6 Bypass Input
Item
Description
Van/Vbn/Vcn Bypass input phase voltage (Voltage is displayed
when single-phase output mode is set.)
Frequency Bypass input frequency
Battery Status
Figure 4-8 Battery Status screen
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 58
