Huawei UPS2000-G Series User Manual

Table 4-31 Discharge Parameters screen (UPS2000-G-6KRTS/UPS2000-
G-10KRTS/UPS2000-G-15KRTL/UPS2000-G-20KRTL)
Item Description Default Value Value Range
Max. time Set the maximum discharge
time. When the discharge
time reaches the value, the
UPS powers o. If you set
the value to 0Hour, the
discharge time is not
limited. The parameter is
congurable in non-battery
mode or non-battery ECO
mode.
NOTE
● If you expect the battery
discharge time to be
greater than 24 hours, set
Max. time to 0 hour.
Otherwise, the system may
power
o.
● If you set Max. time to 0
hour, the battery string
may remain in the small-
current discharge state
according to the proportion
of the battery capacity to
the load power, which
aects the battery lifecycle.
16 hours
0–24 hours
EOD
mode
Determine the power
backup time. The parameter
is congurable in non-
battery mode or non-
battery ECO mode.
Backup time
rst: Ensures
system running and has a
long backup time.
Batt. protect
rst: Protects
batteries and extends the
battery lifespan.
Backup time
rst
Backup time
rst, Batt.
protect rst,
Balanced
mode
EOD
auto-start
Determine whether to
automatically start inverter
output after the mains
becomes normal after EOD.
The parameter is
congurable after the
inverter shuts down.
Enabled Disabled,
Enabled
UPS2000-G-(6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 87

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
