Table 5-32 EOD settings – backup time rst
Expected
Backup
Time
≤ 0.1 CA 0.1CA–
0.5CA
0.5CA–
1CA
1CA–3CA > 3 CA
Low
voltage
warning
threshold
(V/cell)
1.85 1.85 1.85 1.85 1.85
EOD
threshold
(V/cell)
1.75 1.67 1.60 1.60 1.60
Table 5-33 EOD settings – batt. protect rst
Expected
Backup
Time
≤ 0.1 CA 0.1CA–
0.5CA
0.5CA–
1CA
1CA–3CA > 3 CA
Low
voltage
warning
threshold
(V/cell)
1.90 1.90 1.90 1.90 1.90
EOD
threshold
(V/cell)
1.85 1.85 1.83 1.75 1.67
Table 5-34 EOD settings – balanced mode
Expected
Backup
Time
≤ 0.1 CA 0.1CA–
0.5CA
0.5CA–
1CA
1CA–3CA > 3 CA
Low
voltage
warning
threshold
(V/cell)
1.85 1.85 1.85 1.85 1.85
EOD
threshold
(V/cell)
1.80 1.75 1.70 1.67 1.65
● Shallow Discharge screen
