Hubsan MINI - Radio Control System; Radio Control Components Identification

12
2.
2.
radio contol
radio contol
2.1
2.1
Names of components
Names of components
of the adio contol
of the adio contol
1) Smartphone support
A 1-2) Up-Down / Left-Right rotation
B 2-1) Forward/Backward - Left/Right
3) RHT (Return to home)
4) On and off button
5) Speed button:F/N/SFilm mod. -
Normal mod. - Sport mod.
6) Display
7) Button for taking photos
8) Button to record videos
9) Gimbal adjustment
10) Programmable button
11) Antennas
12) Smartphone connection cable
13) Mini USB port for battery charging
and connection.
14) Hole for lanyard.
15) Compartment for storing sticks
16) Compartment for storing the USB
connector
