Hubsan MINI - Radio Control Diagram and Antenna Angle

15
2.4
2.4
radio Contol Diagam
radio Contol Diagam
1
2
3
4
5
6
7
8
9
10
11
12
13
Done battey level
Speed mode
State of the popelles
GPS satellites locked
Done contol signal
radio contol battey level
Heading angle
Infomation aea
Flight height
Flight distance
Compass calibation
Done speed
Photo / Video
2.5
2.5
Angle of the radio Contol antennas
Angle of the radio Contol antennas
1 - Adjust the angle of the an-
tennas and direct them as
much as possible towards the
Drone.
2 - The distance between the
two antennas is adequately
narrow to maintain directivity
for the long distance.
3 - The antennas are appropri-
ately separated to maintain a
wide range of action;
4 - Do not place obstacles and
cross the antennas well.
