INSTALLATION
13
■
Insert the stationary rail bottom bracket into the bottom of the stationary rail.
➤
The bracket fits into grooves at the bottom of the rail.
➤
Insert the bracket with the mounting flanges to the back, away from the fabric stack as
shown. Do not seat the bracket; about
1
⁄
4
" should extend from the rail.
➤
After inserting the bracket, peel off the red label.
Install the Fabric Stack into the Headrail
■
Insert the moving rail onto the moving rail bracket.
➤
The bracket fits into the grooves on the rear of
the vertical rail. Be sure to fit the bracket into
both rear grooves.
➤
Insert the bracket until the bracket catch snaps
into the hole on the back of the rail. Check that
the bracket catch is fully engaged.
Insert Bracket
into Grooves
Rail
