INSTALLATION
14
■
Review the diagram below to familiarize yourself with where the fabric carrier wheels fit
inside the headrail. Note that the headrail is notched to allow insertion of the wheels.
➤
Above the notch is a foam block to keep the wheels in place during installation.
Compress the foam to install the fabric carrier wheels.
■
Insert the fabric carrier wheels into the headrail through the notch on the stationary rail
side, compressing the foam block. (Unwrap a small amount of cord from the orange cord
organizer if you need more slack.)
➤
The wheels with clear stems fit into the rear channel and the wheels with black stems
into the front channel.
NOTE: The fabric carrier wheels only fit into the rail the correct way; it is not possible to
install them into the wrong channel.
IMPORTANT: Do not attach the stationary rail bracket until after inserting all fabric
carriers.
Foam Block
Above Notch
Clear Stem
Black Stem
FRONT
Clear = Rear
Black = Front
To Next Page
