INSTALLATION
20
■
Position the cords.
➤
From the outside of the end plate, place the washer on the end of one cord behind the
slot in the middle of the end plate, so that the cord fits into the slot. Pull the cord taut
to seat the washer.
➤
Cut the knot from the end of the other cord and tie the cord to the cord tensioner using
a square knot. (There are two cord tensioners in the headrail; one is a spare.) Trim the
end of the cord to about
1
⁄
2
".
➤
Loop the cord from the tensioner around the “T” near the front of the end plate.
The top of the loop must be the cord from the cord tensioner. Be sure the cord is
not twisted.
Loop Around
the “T”
Top from
Tensioner
Bottom from
Moving Rail
Washer
Slot
To Next Page
