• Follow the next instructions to adjust the incorrect beveling.
a. The movement of beveled position
+
–
+
–
b. The effect of adding (-) value for the beveled position
c. The movement of polishing in bevel process
+
–
d. The effect of adding (-) for the polished position in bevel process
!
NOTE
Lens
Position
Front
Lens
Position
Rear
Bevel Position
Front
Rear
Lens
Position
