3.14
TRIM CUT
YES
(YES, NO)
Trim Cut function
YES – the machine will perform an initial trim cut before shuttling stock
forward at the beginning of
an Auto Job or Que
NO - the machine will make the rst cut after shuttling stock forward at the
beginning of
an Auto Job or Que
BLADE CLEAR
NO
(YES, NO)
YES – when cycle reaches function of head up, the shuttle will retract the
material away from the blade by 1/8” before the head will move up. When
the head gets to the up position the next length will be shuttled into position.
COOLANT
BLD
(BLD,
BLD+DWN)
Auto Coolant Mode – requires Coolant Switch to be in Auto position
BLD – Coolant ows when blade is running
BLD+DWN – Coolant ows when blade is running and head is descending
QUEUE SINGLE
The QUEUE allows the operator to run several jobs in series. If REPEAT is
selected the above series will be executed the selected number of times
