Hyd-Mech H10A - Shuttle Not Moving in Manual Mode; Cutting Problems Troubleshooting; Vertical Out-of-Square Cutting; Horizontal Out-of-Square Cutting

3.10
5 Shuttle will not move in Manual
Mode
5.1 Both vises closed on material. 5.1 Open appropriate vise.
5.2 Servomotor driver overload.
(Driver displays error code 50)
5.2 Press E-stop and then turn off
Main Disconnect Switch to reset
driver.
Turn on Main Disconnect, pull out
E-stop, and retry.
If overload repeats, repeat E-stop
and Main Disconnect shut-down,
and allow to cool for 30 minutes.
5.3 Servomotor contactor overload
tripped.
5.3 Reset contactor overload
CUTTING PROBLEMS
6 Saw is cutting out-of-square
vertically.
6.1 Excessive feed force. 6.1 Check settings against Saw
Cutting Parameter Chart.
Reduce Feed Rate setting.
6.2 Blade is dull or damaged 6.2 Replace blade.
6.3 Low blade tension. 6.3 Check blade tension display
- adjust tension to between 1000
- 1200 kg
6.4 Too low feed force when cutting
materials that work harden
(stainless steels, nickel alloys)
6.4 Increase feed force setting.
Check that feed rate display does
not drop below 0.20 in/min.
6.5 Stock misalignment. 6.5 Check that stock rests evenly on
conveyor rollers.
6.5 Worn blade guide rollers. 6.5 Replace guide assemblies with
interchange assembly kits.
7 Saw is cutting out-of-square
horizontally
7.1 Stock misalignment. 7.1 Check for bowed stock.
Re-arrange stock.
7.2 Worn blade guide rollers. 7.2 Replace guide assemblies with
interchange assembly kits.
8 Blade comes off blade wheels. 8.1 Low blade tension. 8.1 See 6.3
8.2 Excessive feed force. 8.2 See 6.1
8.3 Blade tracking. too far off
wheels.
8.3 Check tracking, adjust if
necessary.
8.4 Excessive wheel wear. 8.4 Check wheel proles. Replace if
necessary.
9 Blade stalls in cut. 9.1 Low blade tension. 9.1 See 6.3
9.2 Excessive feed force. 9.2 See 6.1
9.3 Blade pinched by stock with
internal stresses.
9.3 Use blade with extra wide set.
10 Blade vibrates excessively. 10.1 Blade speed too high. 10.1 Lower blade speed.
(Occasionally increasing speed
can help.)
10.2 Low blade tension. 10.2 See 6.3
10.3 Not best blade pitch. 10.3 Refer to Saw Cutting Parameter
Chart.
If blade pitch is correct per chart:
In solids, try next ner pitch.
In structurals try next ner pitch.
