5.2
Filter Indicator
Oil Level Gauge
Filler Breather
Cleanout Cover
System Pressure Gauge
Drain Plug
Pump Pressure Adjustment
Oil level should be maintained
at the top portion of the level
gauge glass window.
Filler cap and lter element location
Oil level gauge and drain plug
