4. System Setup
4.19 Thickness of shaft load plate
8
When the new bar length < 300mm, it needs to
install a shaft load plate on the feeding rollers.
If the thickness of plate is 2mm, the loading up
position is 2mm higher than central line.
Setting " Thickness of shaft load plate" = 2mm, and
Select shaft load function the barfeed will make the
loading up position still on the central line
Select system setup item 18 <Thickness of
shaft load plate >
