9. Appendix : Electronic Controller
9.3 Spare Parts List
NO Name Description of goods Placement
E001 32.1
Servo motor
encoder cable
/32.4:E
E002 32.2 Servo motor power cable /32.6:E
E003 33.1 Servo controller cable /33.1:C
E004 33.2 Servo controller cable /33.5:C
E005 50.1 Programming cable /50.3:E
E006 AD1 Inverter /43.0:C
E007 AD2 Inverter /44.0:C
E008 AENC1 Loading mechanism encoder /10.8:D
E009 AENC2 Horizontal mechanism encoder /11.8:C
E010 DA2 Torque/Speed Module /33.4:E
E011 EIB Encoder interfacing board /33.1:E
E012 F4 Fuse t/b with LED DC24V /1.5:F
E082 FTR1 Noise filter /1.4:A
E013 LS1 Proximity switch /11.5:B
E014 LS2 Proximity switch /11.6:B
E015 LS3 Proximity switch /11.7:B
E016 LS4 Thur-beam sensor
/10.4:B
/10.5:B
E017 LS5 Proximity switch /12.3:B
E018 LS6 Proximity switch /12.4:B
E019 M2
3-Phase AC motor
with brake
/43.5:A
E020 M2 Gear box Gear box
E021 M3 3-Phase AC motorwith brake /44.5:A
E022 M3 Gear box Gear box
E086 MSA Power relay + auxiliary contact
/1.6:A
/5.2;B
/5.5:E
/5.6:C
E087 MSB Power relay + auxiliary contact
/1.8:A
/5.5:D
/5.8:E
/12.7:B
E023 PCB1 PC Board set
E024 PLC1 Programmable controller
/2.1:E
/10.0:E
/11.0:E
/12.0:E
/20.0:A
/21.1:A
/22.1:A
/50.1:D
