49
3. User Setup
3.6 Bar rack Angle
A
A ( 1 : 1.5 )
Select .< Bar rack Angle>
The bar rack is fixed and can be adjusted the angle only , the loading position is based on the bar diameter
and the angle of bar rack. Both sides of the bar rack has a angle gauge, check and input the angle value into
ā bar rack angle setting value ā , and the barfeed will calculate the correct loading position.
The barfeed will move horizontally to the loading position first, and lift to the correct bar central position.
