Hydrafeed MSV 65 - 11 Appendix: Mechanism

177
11. Appendix : Mechanism
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
S65-1.5M(H)
S65
MSV65-1500
1 : 20
2015/6/1
A
Top Cover
Magazine
Extension
Touch Screen
Sliding rail - X axis &
Right stand
Transformer set
Sliding rail -
X axis & Left stand
Core Unit
Top Base
Base
