9. Appendix : Electronic Controller
9. Appendix : Electronic Controller
9.1 Input List
Code Description
X0 Servo encoder A pulse
X1 Servo encoder B pulse
X2 Bar length measuring sensor (LS-4)
X3 Servo in position DO1(INP)
X4 Loading bar encoder A pulse
X5 Loading bar encoder B pulse
X6 Servo alarm DO6(ALM)
X7 Servo zero speed DO2(ZSP)
X10 Horizontal movement A pulse
X11 Horizontal movement B pulse
X12 Auto / Manual (S1)
X13 Bar feeder E.M.G stop (S2)
X14 Reference switch (LS-1)
X15 Loading up limit switch (LS-2)
X16 Loading down limit switch (LS-3)
X17 Cover interlock (S4)
X20 Sliding rail interlock (S3)
X21 V Channel in line limit (LS-5)
X22 Main Pushrod in line limit (LS-6)
X23 Chuck open signal
X24 CNC M code signal (Feed command)
X25 CNC Auto mode signal
X26 CNC Emergency stop signal
X27 CNC M code signal (Loading new bar command)
X30 Foot switch (S5)
