7. Alarm List
Alarm
No.
Alarm Picture Cause Action
7
You can’t push the bar.
Bar can not push forward
in the spindle.
(1) Check the bar.
(2) Check the spindle liner.
8
You can’t push the bar.
Pushrod can’t push the
bar to feeding position.
After part off completed,
you can not feed the bar
to setting length “ W “(on
3-3).
Check pushrod, spindle and
turret position.
9
You can’t eject the remnant.
Pushrod can’t go forward
to eject the remnant.
Check the chuck jaws or
spindle.
To Next Page
