144
8. Warning List
Warning
No.
Warning Picture Cause Action
11
Impossible to start auto cycle
because sliding rail is unlocked.
Sliding rail is not in
locked position or there
is a problem at the lock
switch.
-Touch on <NEXT>.
-Move the bar feeder to the
locked position.
-Check the lock switch.
12
Impossible to start auto cycle
because it reached setting
components value.
Bar feeder reached the
value that you set.
-Touch on <NEXT>.
-Write a new big value.
-Write zero into the part
counter.
13
Impossible to start auto cycle
without CNC feed command
CNC without M code
(feed command). You
can’t start auto cycle.
( when you select chuck
open bar check )
-Touch on <NEXT>.
-Use m code in CNC
program.
-If there is still the same
warning, check the M code
(feed command) signal.
To Next Page
