Hydrafeed MSV 65 - Page 187

184
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T04301-000X
S80/65
Idle wheel set
1 : 2.5
2015/3/26
B
Q'ty
Part Number
Item
1
T14206-000X
1
1
T14208-000X
2
1
T14301-000X
3
1
T14302-000X
4
4
Hex socket cap screws-SW Set[M8x1.25x25L]
5
1
Hex socket cap screws-S Set[M5x1.0x16L]
6
4
Hex socket cap screws-S Set[M8x1.25x25L]
7
1
Nut[M10x1.5]
8
4
Nut[M8x1.25]
9
1
Washer[5x16x2.0]
10
4
Washer[8.5x23x2.0]
11
1
Set Screw[M10x1.5x30L]
12
1
Set Screw[M5x0.8x10L]
13
4
Set Screw[M6x1.0x12L]
14
2
Radial Bearing[6003ZZ]
15
1
Double head round keys[5Bx5Hx25L]
16
5
14
4
10
13
162
1
15
12
8
9
3
6
11
7
