Hydrafeed MSV 65 - Page 193

190
1
324
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
S04401-000X
S65
1 : 3
2015/5/28
A
Q'ty
Part Number
Item
1
S14423-000X
1
1
S14702-000X
2
4Hex socket cap screws-S Set[M10x1.5x30L]
3
4
Hex socket cap screws[M5x0.8x20L]
4
1
4
2
3
