Hydrafeed MSV 65 - Page 200

197
1324
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
S25102-002X
S65
Linkage device - 1200
1 : 6
2015/5/28
A
Q'ty
Part Number
Item
8
S05101-000X
1
2
S14603-000X
2
1
S15106-002X
3
2
T05102-000X
4
8
Hex socket cap screws-S Set[M6x1.0x20L]
5
8
Hex socket cap screws[M6x1.0x35L]
6
1
2
4
5
6 3
