Hydrafeed MSV 65 - Page 204

201
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
S21101-000X
S65
1 : 12.5
2015/5/28
Q'ty
Part Number
Item
2
P+F[NBB2-12GM40-E0-5M]
1
1
S11112-000X
2
1
S11119-000X
3
1
S11120-000X
4
4
S11121-000X
5
2
S11122-000X
6
1
S11124-000X
7
2
S14429-000X
8
1
S21303-000X
9
2
T11110-000X
10
4
Hex Socket Pan Head Screw[M5x0.8x12L]
11
24
Hex socket cap screws-SW Set[M10x1.5x30L]
12
12
Hex socket cap screws-SW Set[M6x1.0x12L]
13
4
Hex socket cap screws-SW Set[M8x1.25x55L]14
2Hex socket cap screws-S Set[M8x1.25x35L]
15
4Hex socket cap screws-S Set[M8x1.25x50L]
16
8Hex socket cap screws-S Set[M8x1.25x80L]17
6
Hex socket cap screws[M6x1.0x12L]
18
2
Nut[M16x2.0]
19
6
Nut[M8x1.25]
20
4
Hex head cap screws[M8x1.25x40L]
21
12
Washer[8.5x23x2.0]
22
24
Hex socket flat head screw[M8x1.25x20L]
23
9
4
14
7
1520 23
12
10 619
11
5
2
18 3
8
16 22
13
21
20
22
17
1
1
V Channel in line limit switch
(LS-5)
Main Pusher in line limit switch
( LS-6 )
