Hydrafeed MSV 65 - Page 208

205
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
7.87 kg/ea
STC MACHINERY CO., LTD.
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
DEAN
S21309-000X
S65
Touch screen set
1 : 3
2017/3/3
A
Q'ty
Part Number
Item
1
EMG-Plate
1
1
EMG-Stop
2
1
RESETBOTTOM
3
1
Reset plate
4
1
S11331-000X
5
1
S11332-000X
6
1
S11333-000X
7
1
Switch Plate
8
1
Switch.ipt
9
1
Hex Socket Pan Head Screw -SW Set[M6x1.0x20L]
10
1
Hex Socket Pan Head Screw -SW Set[M6x1.0x12L]
11
1
Touch panel
12
1
Handle
13
1
Hex head cap screws-SW Set[M8x1.25x30L]
14
1
Washer[8.5x23x2.0]
15
1
Spring Washer[8]
16
4
Hex Socket flat head screws[M5x0.8x10L]
17
9
8
3
4
5
6
13
15
7
17
12
1
2
11
10
16
14
