Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3
-
6
.
.
.
.
±
0
.
1
<
3
.
.
.
.
±
0
.
1
G
e
n
e
r
a
l
T
o
l
e
r
a
n
c
e
A4
Rolly
T23103-000X
S80
Sliding rail-X axial
1 : 12
2015/2/11
A
Q'ty
Part Number
Item
2
T13105-000X
1
2
T13106-000X
2
1
T13107-000X
3
2
T13111-000X
4
1T13113-000X
5
1
T13115-000X
6
4
T13117-000X
7
2
T14705-000X
8
1
Telemecanique[XCS-PA791]
9
2
Hex socket cap screws-SW Set[M4x0.7x12L]
10
2
Hex socket cap screws-SW Set[M4x0.7x35L]
11
2
Hex socket cap screws-SW Set[M5x0.8x12L]
12
4
Hex socket cap screws-SW Set[M8x1.25x25L]
13
2
Hex socket cap screws[M10x1.5x50L]
14
18
Hex socket cap screws[M5x0.8x20L]
15
2
Hex socket cap screws[M6x1.0x16L]
16
16
Hex socket cap screws[M6x1.0x20L]
17
4
Hex socket cap screws[M8x1.25x70L]
18
2
Nut-S Set[M10x1.5]
19
4
Nut-S Set[M8x1.25]
20
4
Nut[M10x1.5]
21
2
Nut[M16x2.0]
22
2
Hex head cap screws[M10x1.5x30L]
23
2
Hex head cap screws[M16x2.0x80L]
24
13
17
15
4
1
8
20
11
3
21
18
14
19
7
5
2
23
21
10
9
6
12
24
16
22
To Next Page
