87
4. System Setup
Example (4) :
Chuck open
M code (feed command)
M code (optional)
M-Fin (optional)
If you choose M code (optional)and M-Fin (optional) , the M code (optional) signal is M code
command for bar change.
Note:
(1) To release M code (feed command) by using M code finish (feeding) signal from Bar feeder.
(2) To release M code (optional) by using M-Fin (optional) signal from Bar feeder.
Eject new bar without turret :
Main program:
Chuck open
M code (feed command)
Chuck close
Cutting
/ M98 Pxx (go to sub program)
M99 (Return)
Pxx (Sub program) :
Chuck open
M code (optional)
Chuck close
Part off
M99 (go to main program)
