4. System Setup
(1): CYCLE START
chuck open NO
OR feed warning
command
YES
pushrod check bar
NO
bar in spindle loading new
bar
YES
Confirm Bar reaching
loading
position
M code finish
Signal to CNC lathe
(2): CYCLE START
YES loading
chuck open new bar
NO
pushrod check bar
NO
bar in spindle ALARM
YES
Confirm
bar feeder ready
1. Chuck open bar check 2. Chuck close bar check
