6-6 HySpeed HT2000 Instruction Manual
OPERATION
24
Front Panel Controls and Indicators (cont.)
Digital Remote (DR) V/C Module (Fig. 6-3)
• VOLTAGE Adjust Pot
Adjusts the cutting arc voltage from 100 to 200 volts. Values are chosen from the Cut Charts and depend
on the type of metal to cut, and metal thickness.
• VOLTAGE LEDs
Displays cutting voltage.
• CURRENT Adjust Pot
Adjusts the cutting arc current from 40 amps to 200 amps. Values are chosen from the Cut Charts and
depend on the type of metal to cut, and metal thickness.
• CURRENT LEDs
Displays cutting current.
• UP / DOWN LEDs
Indicates that torch height is being adjusted up or down.
Figure 6-3 Digital Remote (DR) V/C Front Panel Controls and Indicators
UP LED
DOWN LED
CURRENT AdjustVOLTAGE Adjust
