PARTS LIST
HySpeed HT2000 Instruction Manual 9-17
19
HT2000 Power Supply  : High Frequency and I/O PCB
Part
Item Number Description Designator Qty.
029514 HF & I/O PCB SA Pwr Sup/RHF 1
1 004136 Connector, cathode 1
2 004311 Standoff, MAX200 Anode 1
3 004312 Standoff, MAX200 Cathode 1
4 004313 Spacer, .42ID X .750 X .50 lg 1
5 004314 Block, MAX200 Cathode 1
6 015131 Fitting, 3/8 Tube X 1/4 NPT 1
7 015132 Fitting, 90, 3/8 Tube X 1/4 NPT 1
8 015133 Ferrule, 3/8 OD Tube Delrin 2
9 015015 Adapter, 90 1/4 NPT X #6 2
10 015532 Street Elbow 1/4 1
11 041152 Panel, MAX200 Output 1
12 075153 Hexnut, 3/8-16, Finish, Brs 10
13 075156 Hexnut, 1/2-20, Finish/Jam, Brs 1
14 075194 Lkwshr, 3/8, Splitlock, Brz 9
15 075217 Flwshr, 3/8, .390,.875,.063, Brs 2
16 075335 M/S, 8-32 X 1/2, SL, Bin, Nyl 3
17 075347 Bolt, 5/16 X 11/4, Hex, Brz 1
18 075229 Bolt, 3/8-16 X 1 1/2, FTH, Hex, Brs 1
19 075351 Bolt, 3/8-16 X 1, Hex, Brs 1
20 075360 Flwshr, 5/16, .328,.520,.032, Brs 1
21 075361 Flwshr, 3/8, .394, .625, .032, Brs 2
22 009356 Coil, A.C.T., 8G THHN T1 1
23 041145 PC BD Assy MAX200 I/O PCB8 1
24 029202 Current Sensor SA CS1 1
25 015134 Insert, 3/8 OD X .062 Brass 2
26 075072 M/S, 8-32 X 1/2 6
