4-30 HySpeed HT2000 Instruction Manual
19
RHF and Motor Valve Consoles to Torch (cont.)
Connecting the HF Torch Leads to the Torch
Torch Leads – RHF Console to Torch (Fig. 4-17)
A. If connected to the Off-valve subassembly, remove the 12" Off-valve hose from it. Note that the fitting is
left-hand threaded and turns in a clockwise direction to remove.
B. Slide the Torch sleeve over the RHF torch leads and out of the way.
C. With the red and green torch leads, use a 3/8" open-end wrench to hold the torch body fittings and a 1/2"
open-end wrench to turn the torch lead fittings. Attach the leads to the Red and Green tubes of the Torch
main body.
D. Attach the lead with the PTFE tube (Pilot/Shield Gas (Blue)) to the shortest tube (Point 3) on the torch
main body. Use a 5/16" open-end wrench to hold the torch body fitting and a 7/16" open-end wrench to
turn the torch lead fitting.
E. Finally, connect the gray torch lead hose to Point 4. Again, use a 5/16" open-end wrench to hold the torch
body fitting and a 7/16" open-end wrench to turn the torch lead fitting.
Note: If the 12" Off-valve hose is not connected to the torch, make the connection to Point 5
(left-hand threaded connection) at this time. Use the same wrenches as in steps D&E.
F. Slide the Torch sleeve over the torch main body and screw together.
G. Connect the 12" hose that extends beyond the end of the sleeve to the off-valve elbow connected to
Point 2 (left-hand threaded connection).
Connecting the Off-Valve Cable and Plasma Hose from the Torch to the Motor Valve
Console
Cable/Hose: Motor Valve Console to Torch (Fig. 4-17)
A. Connect the Plasma hose from Point 1 (left-hand threaded connection) of the Off-valve subassembly to
the Plasma Flow connector on the motor valve console.
B. Connect the Torch off-valve cable from the Off-valve subassembly to the 4X2 connector on the motor
valve console.
