PARTS LIST
HySpeed HT2000 Instruction Manual 9-29
19
Remote V/C : Digital (DR) Control Station #073007
Part
Item Number Description Designator Qty.
073007 Control Station, Digital Remote V/C MAX200 1
1 002107 Cov: DR/PR V/C Top 1
2 002106 Cov: DR/PR V/C Bottom 1
3 002119 Panel, Rear, DR V/C 1
4 004119 Bracket, Mtg, DR/PR V/C 1
5 008069 Fuse, 3/8 Amp 313, 375 1
6 008165 Fuseholder, REM V/C 1
7 008164 Knob 2
8 014012 Transf'mer, DR/PR/SR V/C 1
002118 Encl, Assy DR V/C 1
9 001133 Pl: HT400 DR V/C MDL FR 1
10 001131 Flg: HT400 DR/PR V/C MDL Fr 1
11 001137 FR: HT400 DR/PR/ST V/C Mdl LS 1
12 001138 FR: HT400 DR/PR/ST V/C Mdl RS 1
029302 Filter PNL-PCB SA DR/SR V/C 1
13 009871 Potentiometer, 500 Ohm 10 turn 2
14 008175 Receptacle, Shell Size 13-9 1
15 008176 Pin, 20-24 AWG Type III+ 6
074016 Term 22-18 .250 FEM QC Insul 2
074038 Term 22-18 FEM QC Insul 11
074041 Term 22-18 #6 Ring Uninsul 1
074067 Term 22-18 .25 MAL QC Insul 2
16 041070 PC BD Assy Opto-Iso 1
008097 Terminal, PC HHS 2022C 4
17 041187 PC BD Assy Dig/Sta V/C MAX200 1
18 004116 Heatsink, DR/PR SR V/C 1
19 042059 IC, LM340AK-5.0 1
20 009274 Capacitor, 2600 UF 15VDC 1
008097 Terminal, PC HHS 2022C 11
008098 Terminal, PC CAM 9
21 041076 PC BD Assy Rem Volt Disp 1
22 041077 PC BD Assy Rem Curr Disp 1
