b-6 HySpeed HT2000 Instruction Manual

19

Figure b-1 Freezing Point of Propylene Glycol Solution

% of Propylene Glycol

Temperature, °F

-70

-60

-50

-40

-30

-20

-10

0

10

20

30

40

0 102030405060
