SPECIFICATIONS
2-8 HySpeed HT2000 Instruction Manual
19
Argon-Hydrogen Manifold (#073109) – Optional
Figure 2-4 Mounting Dimensions - Argon-Hydrogen Manifold
Dimensions and Weight:
Width..........................................................................5" (12.7 cm)
Height ........................................................................10" (25.4 cm)
Depth ........................................................................5" (12.7cm)
Weight........................................................................5-3/4 lb (2.6 kg)
Digital Remote (DR) V/C Control (#073007) – Optional
Controls......................................................................Voltage adjust pot:
Adjusts arc cutting voltage and
displays value on LEDs.
Current adjust pot:
Adjusts arc cutting current and
displays value on LEDs.
Control Range............................................................Current: 40 to 200 Amps
Voltage: 100 to 200 Volts
Control Resolution ....................................................Current: 10 Amps
Voltage: 5 Volts
Dimensions and Weight:
Width..........................................................................11-1/2" (29 cm)
Height ........................................................................3" (7.6 cm)
Depth ........................................................................13-3/8" (34 cm)
Weight........................................................................5 pounds-5 oz. (2.4 kg)
4"
4"
5"
5"
13/64"
dia. (4)
1/2"
typ.
