INSTALLATION

HySpeed HT2000 Instruction Manual 4-23

19

Figure 4-13 Intial Height Sensing Upper Limit Switch Connections

UPPER LIMIT SWITCH

AND CABLE

IHS CONTROL

MODULE

TORCH LIFTER

TB1

S

4

67
