POST-INSTALLATION
HySpeed HT2000 Instruction Manual 5-7
19
If the system does not function as outlined in this procedure, recheck the pre-installation requirements and
installation directions in this manual. If all pre-installation and installation directives have been followed and
you are still experiencing difficulty with the system, feel free to call Hypertherm's Field Service group at
1-800-643-9878.
Figure 5-2 Torch with inductive probes
Leads to RHF Console
and Motor Valve
Console
(Off valve not shown)
Probes
Torch sleeve
Torch mounting
bracket
Securing screw
