Hypertherm Powermax 85 Operator's Manual

TORCH SETUP
3-54 powermax 65/85 Operator Manual
45A Unshielded Air flow rate - slpm/scfh
Aluminum
Hot 147 / 310
Cold 210 / 450
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
1
1.5 3.8 250
0.0 7400 126 12700 119
2 0.1 4400 127 11500 119
3 0.2 2800 129 7800 122
4 0.4 2100 132 5850 123
6 0.5 1050 135 2800 126
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
in in % seconds ipm Volts ipm Volts
1/32 in
0.06 0.15 250
0.0 325 126 500 120
1/16 in 0.1 200 126 500 116
3/32 in 0.2 150 127 410 122
1/8 in 0.4 100 130 280 122
1/4 in 0.5 36 136 90 126
