Hypertherm Powermax 85 Operator's Manual

POWER SUPPLY SETUP
2-12 powermax 65/85 Operator Manual
Extension cord length
< 10 ft
(< 3 m)
10 – 25 ft
(3 – 7.5 m)
25 – 50 ft
(7.5 – 15 m)
50 – 100 ft
(15 – 30 m)
100 – 150 ft
(30 – 45 m)
65 A CSA
Input voltage
(VAC) Phase AWG (mm
2
) AWG (mm
2
) AWG (mm
2
) AWG (mm
2
) AWG (mm
2
)
200–240 1 8 (10) 8 (10) 8 (10) 6 (16) 4 (25)
480 1 12 (4) 12 (4) 12 (4) 10 (6) 10 (6)
200–240 3 10 (6) 10 (6) 10 (6) 8 (10) 6 (16)
400/480 3 12 (4) 12 (4) 12 (4) 12 (4) 12 (4)
600 3 12 (4) 12 (4) 12 (4) 12 (4) 12 (4)
65 A CE
Input voltage
(VAC) Phase mm
2
mm
2
mm
2
mm
2
mm
2
380 3 4 4 4 4 4
400 3 4 4 4 4 4
85 A CSA
Input voltage
(VAC) Phase AWG (mm
2
) AWG (mm
2
) AWG (mm
2
) AWG (mm
2
) AWG (mm
2
)
200–240 1 6 (16) 6 (16) 6 (16) 4 (25) 2 (35)
480 1 10 (6) 10 (6) 10 (6) 8 (10) 8 (10)
200–240 3 8 (10) 8 (10) 8 (10) 6 (16) 4 (25)
400/480 3 10 (6) 10 (6) 10 (6) 10 (6) 10 (6)
600 3 10 (6) 10 (6) 10 (6) 10 (6) 10 (6)
85 A CE
Input voltage
(VAC) Phase mm
2
mm
2
mm
2
mm
2
mm
2
380 3 6 6 6 6 6
400 3 6 6 6 6 6
Extension cord specifications

Hypertherm Powermax 85 Specifications

General

Gas Supply	Clean, dry, oil-free air or nitrogen
Cooling Method	Fan-cooled
Input Voltage	200-600V, 3-phase
Current Output	25-85 A
Duty Cycle	60% @ 85 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Cutting Capacity (Recommended)	1" (25 mm)
Gas Type	Air/Nitrogen
