Hypertherm Powermax 85 Operator's Manual

POWER SUPPLY SETUP
powermax 65/85 Operator Manual 2-13
Engine-driven generator recommendations
Generators used with the Powermax65 or Powermax85 should satisfy the following requirements:
CSA
• 1-phase, 50/60 Hz, 230/240 VAC
• 3-phase, 50/60 Hz, 200-600 VAC (480 VAC recommended for best performance)
CE
• 3-phase, 50/60 Hz, 380/400 VAC (400 VAC recommended for best performance)
Engine drive
rating
System output
current
Performance
(arc stretch)
20 kw 85 A Full
15 kw 70 A Limited
15 kw 65 A Full
12 kw 65 A Limited
12 kw 40 A Full
8 kw 40 A Limited
8 kw 30 A Full
ote:N Based on the generator rating, age, and condition, adjust the cutting current as
needed.
If a fault occurs while using a generator, turning the power switch quickly to OFF and
then to ON again (sometimes called a “quick reset”) may not clear the fault. Instead,
turn OFF the power supply and wait 30 to 45 seconds before turning ON again.
