Hypertherm Powermax 85 Operator's Manual

SPECIFICATIONS
1-6 powermax 65/85 Operator Manual
Powermax65 power supply ratings
Rated open-circuit voltage (U
0
)
CSA, 1-phase, 3-phase
CE, 3-phase
CSA 296 VDC
CE 270 VDC
Output characteristic
1
Drooping
Rated output current (I
2
) 20 – 65 A
Rated output voltage (U
2
) 139 VDC
Duty cycle at 40° C (104° F)
(See data plate on power supply
for more information on duty
cycle.)
CSA
CE
50% @ 65 A, 230 – 600 V, 1/3 PH
40% @ 65 A, 200 – 208 V, 1/3 PH
100% @ 46 A, 230 – 600 V, 1/3 PH
50% @ 65 A, 380/400 V, 3 PH
100% @ 46 A, 380/400 V, 3 PH
Operating temperature 14° to 104° F (-10° to 40° C)
Storage temperature -13° to 131° F (-25° to 55° C)
Power factor
200 – 480 V CSA, 1-phase
200 – 600 V CSA, 3-phase
380/400 V CE, 3-phase
0.99 – 0.97
0.94 – 0.73
0.94
R
sce
– Short Circuit Ratio (CE models only) U
1
– Volts AC rms, 3PH R
sce
400 VAC 225.7
EMC classification CISPR 11 (CE models only)
4
Class A
Input voltage (U
1
)/ Input
current (I
1
) at rated output (U
2
MAX
, I
2 MAX
) (See Section 2,
Power Supply Setup for more
information.)
CSA
CE
2,3
200/208/240/480 V, 1 PH, 50/60 Hz
52/50/44/22 A
200/208/240/480/600 V, 3 PH, 50/60 Hz
32/31/27/13/13 A
380/400 V, 3 PH, 50/60 Hz
15.5/15 A
Gas type Air Nitrogen
Gas quality Clean, dry, oil-free per
ISO 8573-1 Class 1.2.2
99.95% pure
Recommended gas inlet flow
rate/pressure
Cutting: 400 scfh , 6.7 scfm (190 slpm) @ 85 psi (5.9 bar)
Gouging: 450 scfh, 7.5 scfm (210 slpm) @ 70 psi (4.8 bar)

Hypertherm Powermax 85 Specifications

General

Gas Supply	Clean, dry, oil-free air or nitrogen
Cooling Method	Fan-cooled
Input Voltage	200-600V, 3-phase
Current Output	25-85 A
Duty Cycle	60% @ 85 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Cutting Capacity (Recommended)	1" (25 mm)
Gas Type	Air/Nitrogen
