Hypertherm Powermax 85 Operator's Manual

MAINTENANCE AND REPAIR
powermax 65/85 Operator Manual 5-9
Fault
code
Description Power
LED
Fault
LED
Fault
icon
Solutions
0-52 Torch not connected On On • Plug a torch lead into the
FastConnect receptacle
on the front of the power
supply and recycle the
power switch.
0-60 AC input voltage error On On • Phase loss: Check all input
phases and fuses.
• Over voltage: Check the
line, decrease the voltage.
• Under voltage: Check the
line, increase the voltage.
0-61 AC input unstable:
Shutdown
On On • The incoming line current
is unstable. Power down
and correct the line
problem before continuing.
0-98 Internal communication
failure
On On • Power down, wait 20
seconds, power up.
• A qualified service
technician must open the
power supply case and
check the ribbon cable
between the control board
and the DSP board.
0-99 System hardware fault —
service required
Indicates a major fault
with the system.
On On • A qualified service
technician must service
the system. Contact your
distributor or authorized
repair facility.

Hypertherm Powermax 85 Specifications

General

Gas Supply	Clean, dry, oil-free air or nitrogen
Cooling Method	Fan-cooled
Input Voltage	200-600V, 3-phase
Current Output	25-85 A
Duty Cycle	60% @ 85 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Cutting Capacity (Recommended)	1" (25 mm)
Gas Type	Air/Nitrogen
