Hypertherm Powermax 85 Operator's Manual

TORCH SETUP
powermax 65/85 Operator Manual 3-27
Process
Thickness (inches)
22GA 18GA 14GA 10GA 3/16 1/4 3/8 1/2 5/8 3/4
Mild Steel
85A Shielded 0.068 0.071 0.073 0.078 0.090 0.095 0.100
65A Shielded 0.062 0.065 0.068 0.070 0.076 0.088 0.090 0.091
45A Shielded 0.035 0.054 0.055 0.061 0.065 0.066
FineCut 0.024 0.043 0.049 0.051
85A Unshielded 0.070 0.073 0.075 0.080 0.085 0.090
65A Unshielded 0.062 0.064 0.066 0.068 0.075 0.081
45A Unshielded 0.020 0.050 0.051 0.054 0.057 0.059
Stainless Steel
85A Shielded 0.068 0.071 0.073 0.078 0.090 0.095 0.100
65A Shielded 0.062 0.065 0.068 0.070 0.076 0.088 0.090 0.091
45A Shielded 0.035 0.054 0.055 0.061 0.065 0.066
FineCut 0.024 0.043 0.049 0.051
85A Unshielded 0.070 0.073 0.075 0.080 0.085 0.090
65A Unshielded 0.062 0.064 0.066 0.068 0.075 0.081
45A Unshielded 0.020 0.050 0.051 0.054 0.057 0.059
Aluminum
1/32 1/16 1/8 3/16 1/4 3/8 1/2 5/8 3/4
85A Shielded 0.080 0.078 0.075 0.080 0.090 0.095 0.100
65A Shielded 0.073 0.074 0.075 0.076 0.083 0.091 0.100
45A Shielded 0.059 0.061 0.065 0.060
85A Unshielded 0.075 0.075 0.075 0.080 0.082 0.088
65A Unshielded 0.070 0.070 0.070 0.070 0.072 0.079
45A Unshielded 0.062 0.058 0.057 0.061
Estimated kerf-width compensation - English (inches)

Hypertherm Powermax 85 Specifications

General

Gas Supply	Clean, dry, oil-free air or nitrogen
Cooling Method	Fan-cooled
Input Voltage	200-600V, 3-phase
Current Output	25-85 A
Duty Cycle	60% @ 85 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Cutting Capacity (Recommended)	1" (25 mm)
Gas Type	Air/Nitrogen
