Hypertherm Powermax 85 Operator's Manual

TORCH SETUP
powermax 65/85 Operator Manual 3-31
85A Shielded Air flow rate - slpm/scfh
Aluminum
Hot 190 / 400
Cold 235 / 500
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
3
1.5
3.8 250
0.1 8000 122 11800 117
4 0.2 6500 123 10000 118
6
0.5
3800 126 6100 121
8 2650 130 4300 123
10 1920 132 3100 125
12
4.5 300
0.7 1450 134 2400 127
16 1.0 950 139 1500 130
20
Edge Start
600 143 1100 133
25 380 146 670 140
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
in in % seconds ipm Volts ipm Volts
1/8 in
0.06
0.15 250
0.2 300 122 450 117
1/4 in
0.5
130 127 215 122
3/8 in 80 132 130 124
1/2 in
0.18 300
50 135 85 128
5/8 in 1.0 38 139 60 130
3/4 in
Edge Start
25 142 46 132
7/8 in 20 144 36 137
1 in 14 146 25 141
