Hypertherm Powermax 85 Operator's Manual

TORCH SETUP
3-34 powermax 65/85 Operator Manual
65A Shielded Air flow rate - slpm/scfh
Stainless Steel
Hot 160 / 340
Cold 220 / 470
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
2
1.5
3.8 250
0.1 8100 125 12500 122
3 0.2 6700 125 10500 123
4
0.5
5200 125 7700 124
6 2450 126 3600 126
8
0.7
1500 129 2300 127
10
4.5 300
960 132 1550 127
12 1.2 750 135 1150 129
16
Edge Start
500 139 650 134
20 300 143 450 136
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
in in % seconds ipm Volts ipm Volts
16GA
0.06
0.15 250
0.1
345 124 530 121
10GA 240 125 370 123
3/16 in 0.2 155 126 210 125
1/4 in 0.5 80 126 120 126
3/8 in
0.18 300
0.7 40 131 65 127
1/2 in 1.2 26 136 40 129
5/8 in
Edge Start
20 139 25 134
3/4 in 14 142 19 136
