Hypertherm Powermax 85 Operator's Manual

TORCH SETUP
powermax 65/85 Operator Manual 3-39
45A Shielded Air flow rate - slpm/scfh
Aluminum
Hot 147 / 310
Cold 210/ 450
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
1
1.5 3.8 250
0.0 8250 136 12700 136
2 0.1 6600 136 11500 133
3 0.2 3100 139 7800 133
4 0.4 2200 141 6050 134
6 0.5 1500 142 3500 136
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
in in % seconds ipm Volts ipm Volts
1/32 in
0.06 0.15 250
0.0 325 136 500 137
1/16 in 0.1 325 136 500 135
3/32 in 0.2 200 136 410 132
1/8 in 0.4 100 140 280 133
1/4 in 0.5 54 142 120 136
