Hypertherm Powermax 85 Operator's Manual

TORCH SETUP
3-42 powermax 65/85 Operator Manual
FineCut Air flow rate - slpm/scfh
Stainless Steel
Hot 155 / 330
Cold 215 / 460
Metric
Material
Thickness
Amps
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
mm A mm mm % seconds (mm/min) Volts (mm/min) Volts
0.5
40
0.5 2.0 400
0
8250 68 12700 63
0.6 8250 68 12700 65
0.8 0.1 8250 68 12700 64
1
45
0.15 8250 68 12700 65
1.5
0.4
6150 70 10650 64
2 4800 71 8150 64
3 0.5 2550 81 3250 68
4 0.6 1050 84 1250 72
English
Material
Thickness
Amps
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
A in in % seconds ipm Volts ipm Volts
26GA
40
0.02 0.08 400
0.0
325 68 500 68
24GA 325 68 500 65
22GA
0.1
325 68 500 64
20GA 325 68 500 65
18GA
45
0.2 325 68 500 65
16GA
0.4
240 70 410 64
14GA 200 70 345 64
12GA 0.5 120 80 155 67
10GA 0.6 75 83 95 70
